Constant Temperature and Humidity Test Chamber

Application:
Constant temperature and humidity test chamber is applicable to aviation, aerospace, military, electronics, communication, automobile, capacitor, petroleum, chemical industry, medical treatment, pharmacy, machinery, scientific research institutions and other fields.

Model  XZTH-080 XZTH-150 XZTH-225 XZTH-408 XZTH-800
Inner Size (mm) 400*500*400 500*600*500 500*750*600 600*850*800 1000*1000*800
Outer Size (mm) 750*950*570 950*1500*1050 950*1650*1150 1050*1750*1350 1450*1950*1350
Temp. Range -20 ℃ ~ +150 ℃ 0℃ / -20℃ / -40℃/ -60℃/ -70℃ ~ +100 ℃(+150℃)
Relative Humidity Range 20 % ~ 98% RH 20 % ~ 98% RH 20 % ~ 98% RH 20 % ~ 98% RH 20 % ~ 98% RH
Feature Temp. & Humi. Constancy ±0.3 ℃; ±3%RH ±0.2℃(1P) /±0.3℃(2P);±2.5%RH(1P)/±3.0%RH (2P)
Temp. & Humi. Uniformity ±0.5 ℃; ±5%RH ±0.5 ℃; ±3%RH ±0.5 ℃; ±3%RH ±0.5 ℃; ±3%RH ±0.5 ℃; ±3%RH
Indication Resolution 0.1 ℃; 0.1%RH 0.01 ℃; 0.01%RH 0.01 ℃; 0.01%RH 0.01 ℃; 0.01%RH 0.01 ℃; 0.01%RH
Heat-up Time
(20 ℃ ~ HT)
30 100       150 100       150 100       150 100       150
1 30       40 30       45 30       45 30       45
Cooling Time
 (20 ℃ ~ LT)
40 0 -20 -40 -60 -70 0 -20 -40 -60 -70 0 -20 -40 -60 -70 0 -20 -40 -60 -70
1 25 40 50 80 90 25 40 50 80 90 25 40 55 80 90 25 40 75 85 90
Power (KW) AC380V 50/60HZ 3φ AC220V 1φ ; AC380V 50/60HZ 3φ
3.0 3.0 4.0 6.0 6.0 6.0 3.5 5.5 6.5 8.0 8.5 4.5 6.0 7.5 9.5 9.5 5.5 9.0 10.0 10.5 10.5
