Contact Heat IR Oven Line
The infrared tunnel oven is equipped with an internal infrared heat source for drying the products from inside to outside, leading to high drying efficiency. Infrared tunnel ovens are generally used for drying silk screen, signboard and disc printing ink, as well as food processing like biscuit processing and nut processing
| Model | |
| Power | 380V |
| Heating method | IR |
| Length of Feeding Part (mm) | 2950 |
| Length of Heating Part (mm) | 24000 |
| Length of Discharging Part (mm) | 2500 |
| Height of Feeding Inlet and Discharging Outlet (mm) | 100 |
| Width of Wire Mesh Conveyor Belt (mm) | Stainless Steel Mesh 1600 |
| Temperature Range | Room Temperature-400℃ |
| Temperature uniformity (±%) | ±3% |
| Send an Inquiry |
Features:
- High drying efficiency, high capacity.
- High temperature stability, energy saving
- UV drying device is optional. According to the products, users can choose infrared drying or UV drying, leading to reduced cost.
- This infrared tunnel oven can be opened for easy maintenance and repair
- This infrared tunnel oven is suitable for operation continuously or intermittently. Each part can be equipped with a pneumatic or electric door.
