80°C/200°C Vacuum Oven

Product Examples

This vacuum drying oven is specifically designed for drying heat-sensitive products, easily decomposable products and oxidizable products. It is widely used in research field, such as biochemistry, chemical pharmacy, medical and health care, agricultural scientific research, environmental protection, etc. The vacuum oven adopts the SUS stainless steel plate for inner chamber and SS41# cold-rolled sheet for external housing. The temperature fluctuation is ±1℃.

ZKCO-1234

ZKCO-2DF

ZKCO-3F-3D

ZKCO-3T

Model	Power	Max. temperature (℃)	Inner size (W×D×H)(mm)	Outer (W×D×H)(mm)	Vacuum meter	Heating Method	Control method
ZKCO-a	220V,2KW	200	200x200x200	560x420x1260	SMC pointer	Hot Air and radiation heating	Manual control
ZKCO-1	220V,2.5KW	200	300x300x300	660x570x1360
ZKCO-2	380V,3KW	200	400x400x400	750x560x1480
ZKCO-3	380V,5KW	200	500x500x500	860x730x1480
ZKCO-4	380V,6KW	200	610x610x610	970x850x1580
ZKCO-4F	380V,6KW	200	660x750x620	1110x1260x1680	The pressure will be displayed on the touch screen	Hot Air Circulation Heating	Touch Screen +PLC automatic control
ZKCO-5F	380V,9KW	200	700x800x1000	1140x1030x1680
ZKCO-7F	380V,9KW	200	700x800x1500	1340x1030x2230
ZKCO-8F	380V,10KW	80	1200x1200x1500	1740x1520x2350		Water calculation Heating
ZKCO-2F-2D	380V,10KW	200	600x600x400	1240x950x1780		Hot air calculation heating
